8015 SL
- Max Thrust: 14 Kg
- Weight: 420 gms
- IP Rating: IP45
- Design Life: 1000 Hrs
- Nominal Voltage: 48V (12S)
- Propeller Compatibility: Upto 30" inches
- Country of Origin: India
PRODUCT SPECIFICATIONS
8015 100KV
|
Kv (Motor Velocity Constant) |
100 RPM/V |
|
Kt (Motor Torque Constant) |
0.1245 Nm/A @ 2995 rpm |
|
Maximum Continuous Current* |
40 A (180 s) |
|
Maximum Continuous Power* |
1495 W (180 s) |
|
Power Denisity |
2.66 W/g (Rated), 3.895 W/g (Maximum) |
|
Voltage Range |
44V to 52V (12S LiHV) |
|
Io (@48V) |
1.64 A |
|
Inductance per phase (Winding Inductance) |
0.069 mH ( ≃0.03) |
|
Rph (Wind Resistance per phase) |
0.07 Ω ( ≃0.03) |
|
Stator Poles |
36S(36S42P) |
|
Magnetic Poles |
42P(36S42P) |
|
Bearings |
Dual, 619/8 -2Z |
|
Stick Out Shaft Diameter |
ø8 mm |
|
Motor Diameter |
ø88.4 mm |
|
Motor Length |
34mm |
|
Motor Weight |
420g |
|
Mount Pattern @ 90 deg |
4xM4 ↧ 6 mm ø36mm |
|
Propeller Blade Size* |
Max Propller Size - 32inch |
|
Propeller Mount Pattern |
4xM4 ↧5mm ø23mm 4XM3↧ 5mm ø20mm |
|
Propeller
|
Voltage
|
PWM
|
RPM
|
Thrust (g)
|
Torque (N*m)
|
Current (A)
|
Electrical Power
|
Efficiency
|
Temperature (Celcius)
|
|
30 * 10" CFRP Vector Technics Foldable
|
49.8
|
1300
|
1163
|
1346
|
0.62
|
1.9
|
94.6
|
14.5
|
76.9
|
|
49.6
|
1400
|
1570
|
2588
|
1.15
|
4.7
|
233.1
|
11.2
|
77.5
|
|
|
49.2
|
1500
|
2099
|
4881
|
2.06
|
11.1
|
546.1
|
8.9
|
77.5
|
|
|
48.9
|
1600
|
2505
|
6919
|
2.89
|
19.1
|
934
|
7.4
|
77.3
|
|
|
48.4
|
1700
|
2885
|
8919
|
3.67
|
28.7
|
1389.1
|
6.4
|
76.1
|
|
|
47.9
|
1800
|
3207
|
10806
|
4.43
|
40.1
|
1920.8
|
5.6
|
72.9
|
|
|
47.4
|
1900
|
3528
|
12622
|
5.1
|
53.3
|
2526.4
|
5
|
67.7
|
|
|
47.1
|
1950
|
3619
|
13391
|
5.42
|
59
|
2778.9
|
4.8
|
64.6
|
|
|
47.2
|
2000
|
3648
|
13277
|
5.33
|
57.8
|
2728.2
|
4.9
|
60.8
|
|
Kv (Motor Velocity Constant) |
100 RPM/V |
|
Kt (Motor Torque Constant) |
0.1245 Nm/A @ 2995 rpm |
|
Maximum Continuous Current* |
40 A (180 s) |
|
Maximum Continuous Power* |
1495 W (180 s) |
|
Power Denisity |
2.66 W/g (Rated), 3.895 W/g (Maximum) |
|
Voltage Range |
44V to 52V (12S LiHV) |
|
Io (@48V) |
1.64 A |
|
Inductance per phase (Winding Inductance) |
0.069 mH ( ≃0.03) |
|
Rph (Wind Resistance per phase) |
0.07 Ω ( ≃0.03) |
|
Stator Poles |
36S(36S42P) |
|
Magnetic Poles |
42P(36S42P) |
|
Bearings |
Dual, 619/8 -2Z |
|
Stick Out Shaft Diameter |
ø8 mm |
|
Motor Diameter |
ø88.4 mm |
|
Motor Length |
34mm |
|
Motor Weight |
420g |
|
Mount Pattern @ 90 deg |
4xM4 ↧ 6 mm ø36mm |
|
Propeller Blade Size* |
Max Propller Size - 32inch |
|
Propeller Mount Pattern |
4xM4 ↧5mm ø23mm 4XM3↧ 5mm ø20mm |
|
Propeller
|
Voltage
|
PWM
|
RPM
|
Thrust (g)
|
Torque (N*m)
|
Current (A)
|
Electrical Power
|
Efficiency
|
Temperature (Celcius)
|
|
30 * 10" CFRP Vector Technics Foldable
|
49.8
|
1300
|
1163
|
1346
|
0.62
|
1.9
|
94.6
|
14.5
|
76.9
|
|
49.6
|
1400
|
1570
|
2588
|
1.15
|
4.7
|
233.1
|
11.2
|
77.5
|
|
|
49.2
|
1500
|
2099
|
4881
|
2.06
|
11.1
|
546.1
|
8.9
|
77.5
|
|
|
48.9
|
1600
|
2505
|
6919
|
2.89
|
19.1
|
934
|
7.4
|
77.3
|
|
|
48.4
|
1700
|
2885
|
8919
|
3.67
|
28.7
|
1389.1
|
6.4
|
76.1
|
|
|
47.9
|
1800
|
3207
|
10806
|
4.43
|
40.1
|
1920.8
|
5.6
|
72.9
|
|
|
47.4
|
1900
|
3528
|
12622
|
5.1
|
53.3
|
2526.4
|
5
|
67.7
|
|
|
47.1
|
1950
|
3619
|
13391
|
5.42
|
59
|
2778.9
|
4.8
|
64.6
|
|
|
47.2
|
2000
|
3648
|
13277
|
5.33
|
57.8
|
2728.2
|
4.9
|
60.8
|
Performance Data
Thrust Bench data with various propellers
Certifications
Standard Tests and Certifications
CAD FILES
2D / 3D CAD MODEL
