8020 PRO

Precio de ofertaRs. 25,000.00
Agotado

  • Max Thrust: 16 Kg
  • Weight: 710 gms
  • IP Rating: IP45
  • Design Life: 1000 Hrs
  • Nominal Voltage:  48V (12S)
  • Propeller Compatibility: Upto 30" inches
  • Country of Origin: India
KV: 100 Kv

PRODUCT SPECIFICATIONS



Kv (Motor Velocity Constant)

100 RPM/V

Kt (Motor Torque Constant)

0.124 Nm/A @ 3000 rpm

Maximum Continuous Current*

40 A (180 s)

Maximum Continuous Power*

1900 W (180 s)

Power Density

2.70 W/g (Rated),3.81 W/g (Maximum)

Voltage Range

44V to 52V (12S LiHV)

Io (@48V)

2.1 A

Inductance per phase (Winding Inductance)

0.054 mH ( ≃0.03)

Rph (Wind Resistance per phase)

0.07 Ω ( ≃0.03)

Stator Poles

36S(36S40P)

Magnetic Poles

40P(36S40P)

Bearings

Dual, 6001-2RSL

Stick Out Shaft Diameter

ø8 mm

Motor Diameter

ø89.4 mm

Motor Length

45.5mm

Motor Weight

713G

Mount Pattern @ 90 deg

4xM4 ↧ 6.5mm ø40mm

4xM4 ↧ 6.5mm ø51mm

4xM5 ↧6.5mm ø51mm

Propeller Blade Size*

Max Propller Size - 34inch

Propeller Mount Pattern

6xM3 ↧7mm ø71.5mm 4XM4↧ 8mm ø23mm , 4XM3 ↧8mm ø20mm.,





Propeller

Voltage

PWM

RPM

Thrust (g)

Torque (N*m)

Current (A)

Electrical Power

Efficiency

Temperature (Celcius)

30 * 10" CFRP Vector Technics Foldable

49.8

1300

1167

1356

0.6

2

99.6

13.7

66.6

49.7

1400

1599

2578

1.12

4.8

238.6

10.7

66.3

49.4

1500

2101

4611

1.95

10.9

538.5

8.6

65.2

49

1600

2525

6672

2.76

18.6

911.4

7.3

64.1

48.5

1700

2905

8790

3.58

28.5

1382.3

6.4

61.8

48

1800

3236

10743

4.33

39.3

1886.4

5.7

58.8

47.4

1900

3568

12433

4.99

51.5

2441.1

5.1

55.4

47.2

1950

3673

13195

5.27

56.5

2666.8

5

53.1

47.1

2000

3672

13319

5.29

56.7

2670.6

5

51.1



Propeller

Voltage

PWM

RPM

Thrust (g)

Torque (N*m)

Current (A)

Electrical Power

Efficiency

Temperature (Celcius)

32 * 10.6" Mejzlik Foldable

49.9

1300

1187

1356

0.53

1.9

94.8

14.5

69

49.7

1400

1630

2507

0.98

4.4

218.7

11.5

68.7

49.5

1500

2161

4438

1.72

9.8

485.1

9.2

67.6

49.1

1600

2584

6485

2.51

17

834.7

7.7

66

48.6

1700

2968

8694

3.35

26.7

1297.6

6.7

63.9

48

1800

3279

10800

4.21

38.2

1833.6

5.9

60.8

47.4

1900

3572

12959

5.05

51.9

2460.1

5.3

56.7

47.1

1950

3666

13789

5.38

57.4

2703.5

5.1

54.2

47.1

2000

3660

13812

5.41

57.5

2708.2

5.1

52

Performance Data

Thrust Bench data with various propellers

Certifications

Standard Tests and Certifications

CAD FILES

2D / 3D CAD MODEL
